Chapter 2 Servo Specifications
2.2 Servo Drive Naming Rule
C600 S - 40
2.3 Servo Motor Naming Rule
CN7J - 60 04 30 A 3K UAA
Coolmay technology C600 series servo driver
S: Simple servo, can be adapted to 17-bit absolute encoder
The specific power of the servo below 1KW, 40:50W~400W; 75:400W~750W
Power: 04 represents 400W, 08 represents 750W, and so on;.
Maximum speed
（
×100rpm): 30 indicates the rated speed of 3000rpm.
Voltage class, a stands for 220V.
Encoder feedback: 3K represents the absolute value of a single turn of 17bit
magnetic coding, 4K represents the absolute value of multiple turns of 17bit
magnetic coding, and 3a represents the absolute value of 17bit optical coding.
Output shaft type, UAA represents keyed and threaded hole, VBA represents
keyed threaded hole and brake.
1. The code 02430 means the motor rated toque is 2.4Nm and rated speed is
3000rpm.
2. The rated power: P=0.1047×N×T=0.1047×2.4×3000=753.84W≈0.75KW.
T=rated torque, N=rated speed.
