Chapter 5 Running Mode And Controlling Wiring
37
 Digital Output(DO)
Parameter
Introduction
Range
Default Value
FA16
Range of positioning completion
0-3000 pulses
130
FA17
Position deviation limit
0-30000×100 pulses
6000
FA18
Position deviation error
0-1
0
FA83
CWL,CCWL prohibited mode
0-1
0
FA84
Hysteresis for position completion
0-32767
65
FA85
Range for approach positioning
0-32767
6500
FA86
Hysteresis for approach positioning
0-32767
650
 Input And Output Terminals
Parameter
Introduction
Range
Default Value
FA55
Effective level control word for input
terminals
0000-1111
0000
FA57
Effective level control word for output
0000-1111
0000
FA58
Time constant of removing jitter for IO
input terminal
1-20ms
2
F3-0
Digital Input DI1 function
0-99
1
F3-1
Digital Input DI2 function
0-99
2
F3-2
Digital Input DI3 function
0-99
3
F3-3
Digital Input DI4 function
0-99
4
F3-15
Force digital input valid1
00000000-11111111
00000000
F3-16
Force digital input valid2
00000000-11111111
00000000
F3-17
Force digital input valid3
00000000-11111111
00000000
F3-20
Digital Output DO1 function
0-99
18
F3-21
Digital Output DO2 function
0-99
3
F3-22
Digital Output DO3 function
0-99
5
