Chapter 7 Parameters
you need higher torque response frequency, it is
recommended to increase the setting value.
1. To set the characters of speed detection filter.
2. The value is smaller, the cut-off frequency is
lower and noise from the motor is smaller. If the
load inertia is great, reducing the setting value is
recommended. If the value is too small, it would
lead to low response, which would result in
shaking.
3. The value is bigger, the cut-off frequency is
higher and the response frequency is quicker. If
you need higher torque response frequency, it is
recommended to increase the setting value.
Proportional
gain of
position loop
1.To set the proportional gain of position loop .
2.The value is bigger, the gain is higher and its
rigidity is stronger. So the position lag is smaller
under the same frequency command pulse
condition. But if it is too big, it will happen
oscillation.
3.The parameter value is set according to your
exact servo driving system model and the load.
Command
pulses of
each motor
revolution
1.To set command pulses of each motor
revolution.
2.When it is set to 0, FA-12( numerator of
electronic gear for position command pulses),
FA-13(denominator of electronic gear for
position command pulses) are valid.
