1-3-6
2AV/X
1-3
7. Pull the drawer out and remove the tape holding
each of the drawer spacers and then the spacers.
8. Remove the tape holding the fulcrum of the
drawer lift inside the drawer.
9. Remove the tape holding each of the front and
rear cursors.
10. Remove the tape holding each of the drawer claw
spacers and then the spacers.
11. Refit the drawer.
Figure 1-3-5
Figure 1-3-6
Figure 1-3-7
Front cursor
Rear cursor
Drawer claw spacers
Drawer spacers
Fulcrum of the drawer lift
To Next Page
