Copystar CS-2030 - Electrical Problems; The Original Feed Motor Does Not Operate

3A7
1-3-6
(1)
The original feed
motor does not
operate.
(2)
The original
conveying motor
does not operate.
(3)
The copier scans the
contact glass when
originals are loaded
on the DF.
(4)
An original jams
when the main
switch is turned on.
Broken original feed motor
coil.
The connector terminals of
the original feed motor
make poor contact.
Defective DF driver PCB.
Broken original conveying
motor coil.
The connector terminals of
the original conveying
motor make poor contact.
Defective DF driver PCB.
The connector terminals of
DF safety switch 1 make
poor contact.
Defective DF safety
switch 1.
Defective original size
detection PCB.
A piece of paper torn from
an original is caught around
the actuator of the original
size detection PCB.
Defective original size
detection PCB.
A piece of paper torn from
an original is caught around
the DF timing switch.
Defective DF timing switch.
Check for continuity across the coil. If none, replace the original
feed motor.
Reinsert the connector. Also check for continuity within the
connector cable. If none, remedy or replace the cable.
Check for continuity across the coil and connector terminals of
the original feed motor. If present, replace the DF driver PCB.
Check for continuity across the coil. If none, replace the original
conveying motor.
Reinsert the connector. Also check for continuity within the
connector cable. If none, remedy or replace the cable.
Check for continuity across the coil and connector terminals of
the original conveying motor. If present, replace the DF driver
PCB.
Reinsert the connector. Also check for continuity within the
connector cable. If none, remedy or replace the cable.
Check for continuity across the contacts of DF safety switch 1. If
none when the switch is on, replace DF safety switch 1.
With 5 V DC present at CN5-8 on the DF driver PCB, check if
CN5-3 on the DF driver PCB remains high when the actuator on
the machine front side of the original size detection PCB is turned
on and off. If it does, replace the original size detection PCB.
Remove any found.
With 5 V DC present at CN5-8 on the DF driver PCB, check if
CN5-3 on the DF driver PCB remains low when the actuator on
the machine front side of the original size detection PCB is turned
on and off. If it does, replace the original size detection PCB.
Remove any found.
With 5 V DC present at CN5-8 on the DF driver PCB, check if
CN5-1 on the DF driver PCB remains low when the DF timing
switch is turned on and off. If it does, replace the DF timing
switch.
Problem Causes Check procedures/corrective measures
1-3-3 Electrical problems
