2AV/X
1-4-53
1-4
General
Initialization
Drive, paper
feed, paper
conveying and
cooling system
Optical
U000 Outputting an own-status report —
U001 Exiting the maintenance mode —
U004 Setting the machine number —
U005 Copying without paper —
U020 Initializing all data —
U021 Initializing memories —
U022 Initializing backup data —
U030 Checking motor operation —
U031 Checking switches for paper conveying —
U032 Checking clutch operation —
U033 Checking solenoid operation —
U034 Adjusting the print start timing
• Adjusting the leading edge registration 0
• Adjusting the center line 0
U035 Setting folio size
• Length 330
• Width 210
U051 Adjusting the amount of slack in the paper
• Regist data 0
• Feed data 0
U053 Performing fine adjustment of the motor speed
• Drive motor 0
• Polygon motor 0
U060 Adjusting the scanner input properties 12
U061 Turning the exposure lamp on —
U063 Adjusting the shading position 0
U065 Adjusting the scanner magnification
• Main scanning direction/auxiliary scanning direction 0
U066 Adjusting the leading edge registration for scanning an original on the 0
contact glass
U067 Adjusting the center line for scanning an original on the contact glass 0
U070 Adjusting the DF magnification 0
U071 Adjusting the DF scanning timing 0
U072 Adjusting the DF center line 0
U073 Checking scanner operation —
U074 Adjusting the DF input light luminosity 1
U075 Setting the original size detection On
U087 Turning the DF scanning position adjust mode on/off On
U088 Setting the input filter (moiré reduction mode) Off
U091 Checking shading —
U092 Adjusting the scanner automatically —
U093 Setting the exposure density gradient
• Text/text and photo/photo mode 0
U099 Checking the original size detection —
* Initial setting for executing maintenance item U020
Section
Item
Maintenance item contents
Initial
No. setting*
(4) Maintenance mode item list (for 15 cpm copier)
To Next Page
