3A7
2-3-3
Terminals (CN) Voltage Remarks
1-1 1-3, 4 24 V DC 24 V DC supply, input
1-2 1-3, 4 24 V DC 24 V DC supply, input
1-7 1-9, 10 5 V DC 5 V DC supply, input
1-8 1-9, 10 5 V DC 5 V DC supply, input
2-1 1-3, 4 24/0 V DC DFSSW2 off/on, output
2-2 1-9, 10 5/0 V DC DFSSW1 off/on, output
2-4 1-9, 10 0/5 V DC OFM ENABLE signal, input
2-5 1-9, 10 0/5 V DC OFM energization mode signal, input (OFM RET)
2-6 1-9, 10 0/5 V DC (pulse) OFM drive clock pulse, input
2-7 1-9, 10 0/5 V DC OFM rotational direction switching signal, input
2-8 1-9, 10 0/5 V DC OCM ENABLE signal, input
2-9 1-9, 10 0/5 V DC OCM energization mode signal, input (OCM M1)
2-10 1-9, 10 0/5 V DC (pulse) OCM drive clock pulse, input
2-11 1-9, 10 0/5 V DC OCM rotational direction switching signal, input
2-12 1-9, 10 OCM current control voltage, input
2-16 1-9, 10 0/5 V DC OSLSW original size detection (length) signal, output
2-17 1-9, 10 0/5 V DC OSDPCB original size detection (width) signal, output (B)
2-18 1-9, 10 0/5 V DC OSDPCB original size detection (width) signal, output (C)
2-19 1-9, 10 0/5 V DC OSDPCB original size detection (width) signal, output (D)
2-20 1-9, 10 0/5 V DC OSDPCB original size detection (width) signal, output (E)
2-21 1-9, 10 0/5 V DC OSDPCB original present/not present detection signal, output
2-22 1-9, 10 0/5 V DC DFTSW on/off, output
3-1 3-2 24/0 V DC DFSSW2 off/on, input
4-A3 1-9, 10 24 V DC 24 V DC supply for OCM, output (A)
4-A4 1-9, 10 24 V DC 24 V DC supply for OCM, output (B)
4-A5 1-9, 10 0/24 V DC (pulse) OCM motor coil energization pulse, output (A)
4-A6 1-9, 10 0/24 V DC (pulse) OCM motor coil energization pulse, output (B)
4-A7 1-9, 10 0/24 V DC (pulse) OCM motor coil energization pulse, output (A)
4-A8 1-9, 10 0/24 V DC (pulse) OCM motor coil energization pulse, output (B)
4-B1 1-9, 10 24 V DC 24 V DC supply for OFM, output (A)
4-B2 1-9, 10 24 V DC 24 V DC supply for OFM, output (B)
4-B3 1-9, 10 0/24 V DC (pulse) OFM motor coil energization pulse, output (A)
4-B4 1-9, 10 0/24 V DC (pulse) OFM motor coil energization pulse, output (B)
4-B5 1-9, 10 0/24 V DC (pulse) OFM motor coil energization pulse, output (A)
4-B6 1-9, 10 0/24 V DC (pulse) OFM motor coil energization pulse, output (B)
5-1 5-2 0/5 V DC DFTSW on/off, input
5-3 5-2 0/5 V DC OSDPCB original present/not present detection signal, input
5-4 5-2 0/5 V DC OSDPCB original size detection (width) signal, input (B)
5-5 5-2 0/5 V DC OSDPCB original size detection (width) signal, input (C)
5-6 5-2 0/5 V DC OSDPCB original size detection (width) signal, input (D)
5-7 5-2 0/5 V DC OSDPCB original size detection (width) signal, input (E)
5-8 5-2 5 V DC 5 V DC supply for OSDPCB, output
5-10 5-9 5/0 V DC DFSSW1 off/on, input
5-11 5-9 5 V DC 5 V DC supply for DFSSW1, output
6-2 6-1 0/5 V DC OSLSW on/off, input
6-3 6-1 5 V DC 5 V DC supply for OSLSW, output
