Copystar CS-2030 - Page 379

3A6
2-2-2
Figure 2-2-2 Duplex unit
1. Duplex paper conveying switch 1
(DUPPCSW1) .............................................. Detects a paper jam in the duplex unit.
2. Duplex paper conveying switch 2
(DUPPCSW2) .............................................. Detects a paper jam in the duplex unit.
,
,
1
2
Machine front
Machine inside
,
Machine rear
