1-3-2
3B1
Section
Item
Maintenance item contents
Initial
No. setting
Fax U610 Setting the modem output level
• Setting the modem output level —
• Adjusting the modem output level —
U611 G3 cable equalizer
• Setting the G3 transmission cable equalizer —
• Setting the G3 reception cable equalizer —
U612 Setting the modem detection level —
U613 Setting the DTMF output level
• Setting the DTMF (high-frequency group) output level —
• Setting the DTMF (low-frequency group) output level —
U614 Adjusting the DTMF output level
• Adjusting the DTMF (high-frequency group) output level —
• Adjusting the DTMF (low-frequency group) output level —
U615 Setting the NCU
• Setting the connection to PBX/PSTN —
• Setting PSTN dial tone detection —
• Setting busy tone detection —
• Setting for a PBX —
U616 Adjusting the ratio of make-to-break of dial pulses
• Make time (10 PPS) —
• Make time (20 PPS) —
U617 Outputting lists
• Settings list —
• Action list —
• Monitor list —
• Own-status report —
• Protocol list —
• Abbreviated dialing ECM setting list —
• One-touch dialing ECM setting list —
U650 Setting the system 1
• Setting the number of lines to be ignored when receiving a fax
at 100% magnification 3
• Setting the number of lines to be ignored when receiving a fax
in the auto reduction mode 3
• Setting the number of lines to be ignored when receiving a fax (A4R, letter)
in the auto reduction mode 3
• Setting the recording width for inch specifications —
• Setting automatic printing of the protocol list —
U651 Setting the system 2
• Setting the variation range in the auxiliary scanning direction
for rotation reception 3
• Setting the number of adjustment lines for automatic reduction 7
• Setting the number of adjustment lines for automatic reduction
when A4 paper is set 22
• Setting the number of adjustment lines for automatic reduction
when letter size paper is set 26
U660 Setting the system (communication 2)
• Setting the criteria for receiving a TCF signal 2 —
• Setting the short protocol transmission —
• Setting the reception of a short protocol transmission —
• Setting the CNG detection times in the fax/ telephone auto select mode —
• Turning ECM for abbreviated dialing on/off —
• Turning ECM for one-touch dialing on/off —
U670 Setting the system (communication 3)
• Setting if V.34 transmission is available —
• Setting the V.34 symbol speed (3429 Hz) —
• Setting the V.34 symbol speed (3200 Hz) —
• Setting the V.34 symbol speed (3000 Hz) —
• Setting the V.34 symbol speed (2800 Hz) —
U680 Displaying the fax board ROM version —
To Next Page
