Copystar CS-3035 - Intermediate Tray Section

3B5
2-1-3
2-1-2 Intermediate tray section
The intermediate tray section consists of the components shown in Figure 2-1-4. It stores and evens up the paper conveyed
from the paper conveying section and returns the stack of paper to the paper conveying section.
Figure 2-1-4 Intermediate tray section
Figure 2-1-5 Intermediate tray section block diagram
Trailing edge registration cursor
Intermediate tray
Front side registration cursor
Rear side registration cursor
SRFHPS
MPCB
CN5-1-
CN5-5
CN4-12 CN4-14 CN4-26
SRRHPS
TERHPS
CN5-6-
CN5-10
CN6-1-
CN6-4
FSRM RSRM TERM
