Copystar CS-3035 - Drive System

3CC
1-1-4
1-1-4 Drive system
9
84
3
7
2
1
5
6
As viewed from machine front
Figure 1-1-3 Drive system
1 Desk drive motor gear
2 Idle gear 67/34
3 Gear 41
4 Desk upper paper feed clutch gear
5 Gear 41
6 Desk lower paper feed clutch gear
7 Gear 20
8 Gear 26
9 Desk feed clutch gear
