3B5
2-4-2
Timing chart No. 2
SRFHPS CN4-12
FSRM CN5-1,
2, 3, 5
SRRHPS CN4-14
RSRM CN5-6,
8, 9, 10
TERHPS CN4-26
TERM CN6-1,
2, 3, 4
STM CN6-13,
14, 15, 16
STHPS CN4-16
SRFHPS CN4-12
FSRM CN5-1,
2, 3, 5
SRRHPS CN4-14
RSRM CN5-6,
8, 9, 10
TERHPS CN4-26
TERM CN6-1,
2, 3, 4
SRFHPS CN4-12
FSRM CN5-1,
2, 3, 5
SRRHPS CN4-14
RSRM CN5-6,
8, 9, 10
TERHPS CN4-26
TERM CN6-1,
2, 3, 4
Sort end
Moving to stapling position
Stapling
Moving to
shift-eject
position
To batch
ejection
Sort end To batch
ejection
135 ms 135 ms
135 ms
Moving to
shift-eject
position
Sort end To batch
ejection
Moving to
shift-eject
position
300 ms
Stapling operation
Non-stapling operation (for front-shift ejection)
Non-stapling operation (for rear-shift ejection)
