Terminals (CN) Voltage Remarks
3CC
2-3-3
1-1 1-9 5 V DC 5 V DC supply for DLICSW-U, output
1-2 1-10 5 V DC 5 V DC supply for DPSW-U, output
1-3 1-11 5 V DC 5 V DC supply for DLICSW-L, output
1-4 1-12 5 V DC 5 V DC supply for DPSW-L, output
1-5 1-9 5/0 V DC DLICSW-U on/off, input
1-6 1-10 0/5 V DC DPSW-U on/off, input
1-7 1-11 5/0 V DC DLICSW-L on/off, input
1-8 1-12 0/5 V DC DPSW-L on/off, input
1-13 5-8 0/24 V DC DPFCL-L on/off, input
1-14 5-8 24 V DC 24 V DC supply for DPFCL-L, output
1-15 5-8 0/24 V DC DPFCL-U on/off, input
1-16 5-8 24 V DC 24 V DC supply for DPFCL-U, output
2-1 5-8 0/24 V DC DFCL on/off, input
2-2 5-8 24 V DC 24 V DC supply for DFCL, output
2-3 5-8 0/24 V DC DCLM-L on/off, input
2-4 5-8 24 V DC 24 V DC supply for DCLM-L, output
2-5 5-8 0/24 V DC DCLM-U on/off, input
2-6 5-8 24 V DC 24 V DC supply for DCLM-U, output
2-7 2-9 0/5 V DC DFSW on/off, output
2-8 2-9 5 V DC 5 V DC supply for DFSW, output
2-15 2-13 0/5 V DC Paper level detection switch on/off, input
2-16 2-14 0/5 V DC Paper level detection switch on/off, input
2-17 2-13 0/5 V DC Paper level detection switch on/off, input
2-18 2-14 0/5 V DC Paper level detection switch on/off, input
3-1 3-9 0/5 V DC DPWSW-U (DIG0) on/off, input
3-2 3-9 0/5 V DC DPWSW-U (DIG1) on/off, input
3-3 3-9 0/5 V DC DPWSW-U (DIG2) on/off, input
3-4 3-10 0/5 V DC DPWSW-L (DIG0) on/off, input
3-5 3-10 0/5 V DC DPWSW-L (DIG1) on/off, input
3-6 3-10 0/5 V DC DPWSW-L (DIG2) on/off, input
3-7 3-11 0/5 V DC DPLSW-U on/off, input
3-8 3-12 0/5 V DC DPLSW-L on/off, input
4-1 4-2 24 V DC 24 V DC supply for DDM, output
4-4 4-3 5 V DC 5 V DC supply for DDM, output
4-5 4-2 0/5 V DC (pulse) Clock signal to DDM, output
4-6 4-2 0/5 V DC DDM on/off, output
4-7 4-2 0/5 V DC LOCK signal to DDM, input
5-1 5-2 0/5 V DC FSW3 on/off from the copier, input
5-3 5-2 0/5 V DC (pulse) Serial communication signal to the copier, output
5-5 5-4 0/5 V DC (pulse) Serial communication signal to the copier, input
5-6 5-7 5 V DC 5 V DC supply, input
5-10 5-8 24 V DC 24 V DC supply, input
6-1 5-8 24/0 V DC DSSW on/off, input
6-3 5-8 24 V DC 24 V DC supply for DSSW, output
