Copystar CS-3035 - Page 479

3CP
2-4-1
SBFISW CN5-3
Copying start
• Paper size: A4R/81/2"
× 11"
• Paper size: A3/11"
× 17"
The timing of all the motors and the solenoids is controlled based on the ON edge of the switchback feed in switch (SBFISW) as
the starting point.
Fwd. rotation
Rev. rotation
Fwd. rotation Fwd. rotation
Rev. rotation
First paper
Copying start
Fwd. rotation
Rev. rotation
First paper
Fwd. rotation Fwd. rotation
Rev. rotation
Second paper
Second paper
SBESW CN5-4
SBEM CN3-1,2,3,4
SBFM CN4-1,2,3,4
PRSOL
(release)
CN5-12
PRSOL
(acutuate)
CN5-14
SBFISW CN5-3
SBESW CN5-4
SBEM CN3-1,2,3,4
SBFM CN4-1,2,3,4
PRSOL
(release)
CN5-12
PRSOL
(acutuate)
CN5-14
Timing chart No. 1
