5FF
1-3-7
Code
C1130
C1160
C1170
C2600
Causes
Defective paper
deck motor 1.
Poor contact of
paper deck motor
1 connector termi-
nals.
The deck left lift
does not rise
properly.
Operation start
request is sent
from the copier to
the large paper
deck while paper
feed is disabled.
Paper feed re-
quest is sent from
the copier to the
large paper deck
before operation
start request.
Deck for the
printer is installed.
Defective deck
conveying motor
PCB.
Deck conveying
motor does not
rotate correctly
(the motor is over-
loaded).
Poor contact in
the deck convey-
ing motor connec-
tor terminals.
Check procedures/corrective measures
Check for continuity across the coil. If
none, replace paper desk motor 1.
Reinsert the connector. Also check for con-
tinuity within the connector cable. If none,
repair or replace the cable.
Check the gears and belts, and remedy if
necessary.
Turn the power off and back on (reset re-
quest is sent from the copier to the large
paper deck to cancel operation start
request).
Turn the power off and back on (reset re-
quest is sent from the copier to the large
paper deck to cancel operation start re-
quest).
Replace the deck fot the copier.
Replace the deck conveying motor PCB
and check for correct operation.
Check the gears and remedy if necessary.
Reinsert the connector. Also check for con-
tinuity within the connector cable. If none,
remedy or replace the cable.
Contents
Deck left lift position problem
Deck level switch 2 does not turn on
within 30 s of paper deck motor 2 turn-
ing on.
Sequence problem
Large paper deck incorrect type
problem
Deck paper conveying motor prob-
lem
No pulse is input within 500 ms of the
start-up.
No pulse is input within 100 ms of the
previous pulse input.
Remarks
