Coretec BS Series - Page 58

BS Controller for AC SERVO PRESS
Instruction Manual Ver1.08
BS-M3A-1B
- 58 -
range-load cell
type.
tool table. Please refer to the details of a tool table.
218
Outside of the
range-current
limit.
Abnormalities were discovered by the contents of a
tool table. Please refer to the details of a tool table.
308
Outside of the
range-
stop speed
ratio.
Abnormalities were discovered by the contents of a
tool table. Please refer to the details of a tool table.
309
Outside of the
range-deceleration.
Abnormalities were discovered by the contents of a
tool table. Please refer to the details of a tool table.
310
Outside of the
range-deceleration
ratio.
Abnormalities were discovered by the contents of a
tool table. Please refer to the details of a tool table.
400
Outside of the
range-control
mode.
They are the abnormalities of a control mode
parameter. Incorrect operati
on of a microcomputer is
suspected. Repair is required, if, so that it may occur
frequently.
401
Over limit-target
stroke.
Since there was a possibility of the stroke limit having
been exceeded or exceeding, it went into the stop
mode.
402
Over limit-target
speed.
The speed target value exceeding the limit was set up.
404
Inconsistency of
pulus limits.
- side of stroke restriction value was set up more
greatly than + side.
410
Outside of the
range-stroke mode.
The parameter in the positioning mode is unusual.
Incorrect operation of a microcomputer is suspected.
Repair is required, if, so that it may occur frequently.
411
Outside of the
range-acceleration
time.
The setting value of acceleration time is over the
range. Please improve a setup of a tool tab
le or check
a tool setup.
530
Z phase ditected
wrong timing.
The encoder incorrect-counted. Incorrect operation by
the abnormalities in an encoder cable and the noise
can be considered. Please add filters, such as a ferrite
core, to a noise generation source.
532
ABZ of encoder
alarm.
Disconnection detection of an encoder cable operated.
Please check the plug of a connector.
536
Z-phase lost
Z phase of the encoder was not detected more than a
fixed term.
The failure relevant to an encoder cable or
an encoder is suspected.
540
Limit over-stroke.
The stroke limit was exceeded. Please move by
manual operation after reset at within the limits.
550
Limit over-current
in origin mode.
Current restriction value was exceeded at the time of
origin. In such a case
, the big load at the time of
origin
should set the concerned part of a tool table as
proper value.
551
Limit over-stroke
in origin mode.
The stroke range currently assumed by origin
sequence was exceeded. The abnormalities of an
originsensor is suspected.
552 Limit over-
load in
origin mode
Load restrictions worked before origin finished.
Please check
whether there is any nothing that bars a motion of ram.
553
Load cell recieve
The communication state with load cell amplifier is not good.
