TigoMaster 2TH – PROFINET User Manual
Page 14 of 69
Function
Number
Name
Description
Device
identification
(26)
-
QR code
(27)
-
Product group and model
(35)
-
Part number, model, MAC address
(36)
-
Serial number
(19)
-
Device labeling field
Manufacturer
(37)
Manufacturer address
Technical data
(3), (5)
-
Certification sings (CE) and IDs (placeholders)
(4)
-
Power supply (SELV / PELV), fuse protection, temperature
range, protection class
Safety and
disposal
(2), (1)
-
Signs on safety and environment (disposal)
Mounting
(1)
-
Mounting hole (up) and grounding
(13)
-
Mounting hole (down)
3.2.2. Lasering
All technical data, such as the manufacturer’s address, product name, part number, serial number, MAC
address, certification signs (i.e., CEL, UL, etc.), environmental signs (i.e., disposal, etc.), and other data
alike is provided in the form of lasering on the right- or left-hand side of the device’s housing.
See Section 8 Technical Data for further technical details.
3.2.3. Revisions and Versions
The device’s hardware revision listed in Table 2 functionally belongs with the software and firmware
versions listed in Table 3 and Table 4 below. With any hardware installation, firmware must be updated.
Table 2: TigoMaster 2TH Hardware
Product Name
Description
Part Number
Hardware
Revision
TigoMaster 2TH-
PROFINET
IO-Link Wireless Master (PROFINET
Version)
CT241-0003t2-
01
Rev03
Table 3: TigoMaster 2TH Software
Software
Name
Version
Engineering Tool
TigoEngine
1.5
Integrated Web Server
netFIELD
1.2
PLC IDE
TIA Portal
V16
Table 4: TigoMaster 2TH Firmware
