Warning:
During operation, high surface temperatures can occur on the housing and at the metal
connections, especially at the M12 connector sleeve. After the device is in operation, let it
cool down before touching it or use gloves.
Disposal of waste electronic equipment
Important notes from the European Directive 2021/19/EU “Waste Electrical and Electronic
Equipment (WEEE)”.
Waste electronic equipment
This product must not be treated as household waste.
This product must be disposed of at a designated waste electronic equipment collecting point.
Waste electronic equipment may not be disposed of as household waste. As a consumer, you are legally
obliged to dispose of all waste electronic equipment according to national and local regulations.
4.2. Connections and Booting
Warnings
Adhere to the warnings hereafter before you connect the network cable and the power supply cable to the
IO-Link Wireless Master device. In case of ignoring this, there is a risk of electrical shock.
• Danger from electrical shock, SELV or PELV power supply required.
• Operate the device exclusively with 24 V DC SELV (Safety Extra Low Voltage) or PELV
(Protective Extra Low Voltage) power supply.
• Always use two separate supply lines/power supplies for 1L and 2L to supply the devices.
• Pay attention to a central grounding (FE) if two separate power supplies are used.
Device Destruction and Fuse Protection
The maximum supply current must not be exceeded and must be fused with an external fuse (16 A).
Otherwise, the risk of device destruction cannot be excluded, damage to the printed circuit board and the
connecting plug.
Connection Example with TigoBridge
The connection example described hereafter shows a typical installation that uses a TigoBridge to
connect a wired IO-Link device via a wireless connection to the IO-Link Wireless Master device.
Requirements:
• L-Coded M12 power cable
