TigoMaster 2TH – PROFINET User Manual
Page 61 of 69
Category
Parameter
Value
communication
technology
equipment - Part 1: Safety
requirements
RoHS
Complied
Firmware download
Software to download and
update the firmware
TigoEngine and Integrated Web Server
Configuration
Configuration software
TigoEngine, Integrated web server, PLC IDE
Electrical
specifications
Frequency Range
2400-2500 MHz
Max Gain
1.6 dBi
Impedance
50Ω
Polarization
Vertical
Radiation
Omni
Mechanical
specifications
Connector
Regular SMA-Male
8.2. Protocol Specifications
Table 41: Protocol Specifications
Parameter
Value
Connection 1 “Exclusive Owner - 32 bytes per IO-
Link Port with Config”
Input data: 276 bytes, Output data: 276 bytes
Connection 2 “Exclusive Owner - 32 bytes per IO-
Link Port without Config”
Connection 3 “Listen Only - 32 bytes per IO-Link”
Input data: 276 bytes, output data: 0 bytes
Connection 4 “Input Only - 32 bytes per IO-Link”
Connection 5 “Exclusive Owner - 16 bytes per IO-
Link Port without Config”
Input data: 292 bytes, Output data: 292 bytes
Connection 6 “Listen Only - 16 bytes per IO-Link”
Input data: 292 bytes, output data: 0 bytes
Connection 7 “Input Only - 16 bytes per IO-Link”
Connection 8 “Exclusive Owner - 4 bytes per IO-Link
Port without Config”
Input data: 100 bytes, Output data: 100 bytes
Connection 9 “Listen Only - 4 bytes per IO-Link”
Input data: 100 bytes, output data: 0 bytes
Connection 10 “Input Only - 4 bytes per IO-Link”
I/O connection types (implicit)
Exclusive owner Input Only
