CoreTigo TigoMaster 2TH-PROFINET User Manual

Copyright © 2021 CoreTigo Ltd.
TigoMaster 2TH – PROFINET User Manual
Page 16 of 69
Blinking (3x Yellow,
3x Green)
The indicator turns on and off with a frequency of approx. 1 Hz:
• 3x yellow "On" for 500 ms and "Off" for 500 ms
• 3x green "On" for 500 ms and "Off" for 500 ms
Blinking (1 Hz, 4 Hz)
The indicator turns on in phases yellow or green with a frequency of
approximately:
• 1 Hz: 1 x yellow "On" for 500 ms and 1 x green "On" for 500 ms
• 4 Hz: 1 x yellow "On" for 125 ms and 1 x green "On" for 125 ms
3.2.5.2. APL LEDs
Table 7: APL LEDs
LED
Color
State
Description
APL
Green
On
IO-Link Wireless Master configured
Green
Blinking
Communication established
Yellow
On
Initialization of components done
Red
Blinking
Communication error
Grey
Off
Components not initialized
3.2.5.3. Supply Voltage LEDs
Table 8: Supply Voltage LEDs
LED Type
Color
State
Description
1L
Green
On
1L supply voltage OK
Grey
Off
No 1L supply voltage
2L
Green
On
2L supply voltage OK
Grey
Off
No 2L supply voltage
3.2.5.4. PROFINET IO-Device status
The SF (system failure) and BF (bus failure) LEDs indicate the status of the PROFINET IO-Device. The
LNK and ACT LEDs indicate the status of the Ethernet.
The following table describes the LED states of the PROFINET IO-Device.
Table 9: PROFINET IO-Device status
LED
Color
State
Description
SF
(System Failure)
(off)
Off
No error
(red)
Flashing
(1 Hz, 3 s)
DCP signal service is initiated via the bus.
(red)
On
Watchdog timeout; channel, generic or extended
diagnosis present; system error
