The TigoMaster 2TH verifies the calculated I-Am-Alive Time with the following limits:
• Minimum I-Am-Alive Time = W-Sub-cycle duration [ms] * (MaxRetry + 1)
• Maximum I-Am-Alive Time = 10 minutes
5.6.3. Parameters to Be Set for Connection 1
When using connection 1, the parameters in Table 25 – Table 27 must be set.
Table 25: Parameters 10 to 85
The port is inactive. L+ is turned off, Input and
Output Process Data is 0.
Target mode based on user defined configuration
including validation of Vendor ID, Device ID, and
Revision.
Target mode without configuration, Validation: No
Device Check.
There is no device check for validation or backup of
connected IO-Link slave devices.
Type Compare*, No
Backup/Restore
A device check is performed for validation of
connected IO-Link slave devices of the specified
device type, without backup/restore.
Type Compare*,
Backup Only
A device check is performed for validation or backup
of connected IO-Link slave devices of the specified
device type, without restore.
Type Compare*,
Restore Only
A device check is performed for validation or restore
of connected IO-Link slave devices of the specified
device type, without backup.
Type Compare*,
Backup and
Restore
A device check is performed for validation or
backup/restore of connected IO-Link slave devices of
the specified device type.
No Type Compare*,
No Backup/Restore
A device check is performed for validation of
connected IO-Link slave devices, without type
compare, without backup/restore.
No Type Compare*,
Backup Only
A device check is performed for validation or backup
of connected IO-Link Slave devices, without type
compare, without restore.
No Type Compare*,
Restore Only
A device check is performed for validation or restore
of connected IO-Link Slave devices, without type
compare, without backup.
