TigoMaster 2TH – PROFINET User Manual
Page 45 of 69
No.
Name
Value Range
Default
Description
No Type Compare*,
Backup and
Restore
A device check is performed for validation or
backup/restore of connected IO-Link Slave devices,
without type compare.
13, 23, …
Port
Cycle
Time
0 ... 255
0
See Table 22 on page 42.
14, 24, …
Vendor ID
0 … 65535
0
Vendor ID – See the documentation of the
manufacturer of the sensor/actuator used.
15, 25, …
Device ID
0 … 4294967295
0
Device ID – See the documentation of the
manufacturer of the sensor/actuator used.
Table 26: Parameter 90
No.
Name
Value Range
Default
Description
90
DIO
Process
Data Layout
Port Based (IQ/CQ,
IQ/CQ, IQ/CQ, …)
Port Based
Sequence of the process data of the digital inputs
and digital outputs: Port 1 (Bit 0 and 1), Port 2 (Bit 2
and 3), ..., Port 8 (Bit 14 and 15). For each port first
pin 4 then pin 2 is transmitted.
Pin Based (IQ, IQ, IQ,
… CQ, CQ, CQ, …)
The sequence of the process data of the digital
inputs and digital outputs: Pin 4 (Port 1 to 8), pin 2
(Port 1 to 8).
