CoreTigo TigoMaster 2TH-PROFINET User Manual

Copyright © 2021 CoreTigo Ltd.
TigoMaster 2TH – PROFINET User Manual
Page 51 of 69
7. Status and Diagnosis
7.1. TigoMaster 2TH
See Section 3.2.5 of this manual for further details on LED indications.
7.2. PROFINET
The IO-Link Wireless Master contains the Event Log object with information about IO-Link events. The
PLC can read attributes of the Event Log object, to get the “Event Qualifier” and “Event Code“ of an IO-
Link Event. Each IO-Link port has an assigned CIP instance.
The Event Log Object contains information on IO-Link events.
7.2.1. Instance 0 (Class Attributes)
Table 32: Class Attributes Event Log Object 65 (0x41)
Attribute
Name
NV
Access
Data type
Description
Default
1
Revision
NV
Get
UINT
Revision of this object
1
2
Max.
Instance
NV
Get
UINT
Number of IO-Link ports
1 – 8
32
Time
Format
NV
Get
USINT
Data type code of time format
Only data type STIME is
supported.
204 (0xCC)
= STIME
33
Present
Time
NV
Get
STIME
Default for time value
Applies to all instances.
0
7.2.2. Instances 100, 101, … (Instance Attributes)
The following table shows the mapping of CIP instances to the IO-Link ports.
Table 33: Mapping CIP Instances to IO-Link Ports
IO-Link port
CIP instance
1
100
2
101
3
102
…
…
