Copyright © 2021 CoreTigo Ltd.
TigoMaster 2TH PROFINET User Manual
Page 50 of 69
Table 30 shows an example of track and double slot configuration for an IO-Link wireless device.
Table 30: Track and Slot (Double-Slot)
Track
Slot 0
Slot 1
Slot 2
Slot 3
Slot 4
Slot 5
Slot 6
Slot 7
0
W-Device with DSlot
Free
Free
Free
Free
Free
Free
1
Free
Free
Free
Free
Free
Free
Free
Free
If the slot type is DSlot, then the slot value must be an even number.
Table 31 shows an example of track and single slot configuration for an IO-Link wireless device.
Table 31: Track and Slot (Single-Slot)
Track
Slot 0
Slot 1
Slot 2
Slot 3
Slot 4
Slot 5
Slot 6
Slot 7
0
W-Device
with SSlot
Free
Free
Free
Free
Free
Free
Free
1
Free
Free
Free
Free
Free
Free
Free
Free
If the slot type is SSlot, then the slot value must be an even number
