CoreTigo TigoMaster 2TH-PROFINET User Manual

Copyright © 2021 CoreTigo Ltd.
TigoMaster 2TH – PROFINET User Manual
Page 58 of 69
8. Technical Data
8.1. Product Specifications
Table 40: Product Specifications
Category
Parameter
Value
Product
Part number
1912.122
Product name
TigoMaster 2TH
Description
TigoEngine PROFINET/IP IO-Link Wireless Master
Function
• IO-Link Master Wireless for PROFINET
• 2 tracks, 16 channels
• Connector/housing: 30 mm
Communication
controller
Type
netX 90
Integrated memory
RAM
16 MB SDRAM
FLASH
8 MB
Ethernet
communication
Real-Time Ethernet
Ethernet Adapter
Ethernet interface
Interface type
100BASE-TX, 10BASE-T, isolated
Auto-negotiation, Auto
crossover
Yes
Connectors
X31: Ethernet interface, M12, D-coded, PROFINET
port 1, X32: Ethernet interface, M12, D-coded,
PROFINET port 2
IO-Link
Radio
2 track = 16 IO-Link wireless salves, 3 antennas, 16
LEDs
LEDs
System and application
SYS
System status
green/ yellow
APL
Application status
red/green
Power supply
1L (X21)
1L power supply (DC
24 V)
red/green
2L (X21)
2L power supply (DC
24 V)
red/green
PROFINET IO
communication
SF
Status Failure
red/green
BF
Bus Failure
red/green
Ethernet
LINK (X31)
Link status, connector
X31
green
