TigoMaster 2TH – PROFINET User Manual
Page 59 of 69
Category
Parameter
Value
ACT (X31)
Activity status,
connector X31
yellow
LINK (X32)
Link status, connector
X32
green
ACT (X32)
Activity status,
connector X32
yellow
Wireless tracks
WT01 ...
WT03
IO-Link wireless track
status, antenna X1 …
X3
red/yellow/
green
Wireless ports
wireless IO-Link ports 1 to
8
WP01 ...
WP08
Port status
red/yellow/
green
Power supply 1L, 2L
Voltage supply
24V DC, –25%/+30% (18 V DC … 31,2 V DC)
Power consumption (w/o
DI/DO)
1L: 0.2 A (at 24 V DC), 2L: 0.1 A (at 24 V DC)
Connectors
X21: Power supply input (Power In), M12, L-coded,
X22: Power supply output (Power Out), M12, L-
coded
Power consumption
(power connectors)
Max. 16 A, Max. current of the device including pass
through must not exceed 16 A for 1L and 2L
Revers polarity protection
Yes
Voltage supply
24V DC, –25%/+30% (18 V DC … 31,2 V DC)
Power consumption (w/o
DI/DO)
1L: 0.2 A (at 24 V DC), 2L: 0.1 A (at 24 V DC)
Ambient conditions
Ambient temperature
range (working)
-25 °C ... +55 °C
Ambient temperature
(non-working, storage)
-40 °C ... +85 °C
Max. temperature change
3 K / min
Humidity
5 … 95% relative humidity, no condensation
permitted
Operating height
0 … 2000 m
Over voltage category
II (EN 60664-1)
Device
Dimensions (L x W x H)
200 x 30 x 20 mm
Housing
Plastics
