Copyright © 2021 CoreTigo Ltd.
TigoMaster 2TH – PROFINET User Manual
Communication to Wireless Device (IO-Link
Device is connected to Bridge)
Communication loss to IO-Link Device (IO- Link
Device is disconnected from TigoBridge)
Check connection from IO-
Link Device to the TigoBridge
Max Retry error, indicating a packet loss
The W-Master cannot create a message to W-
Device after MaxRetry attempts.
This error indicates that one packet failed to be
transmitted successfully. This can be for example
the result of a noisy environment (RF-wise). It
affects the PER of the system.
If the PER is too high, it
would require checking the
configuration of the system
(ranges, operating channels,
etc.).
IMA timeout
The W-Master did not receive a message from the
connected W-Device within the IMA timeout. This
error indicates that the IOLW connection failed.
Possibly this leads to "Communication loss"
0xFF22.
Check connection from IO-
Link Device to the TigoBridge
7.3.3. IO-Link Device Event Codes (Common)
The following table lists standard IO-Link Device Event Codes. For device- specific Event Codes or
remedy, refer to the manual for the IO-Link Device used.
Table 39: Device Event Codes
General malfunction (unknown error)
See manual of the used IO-
Link Device
See manual of the used IO-
Link Device
Temperature fault – overload
Check temperature, find
source for overload
Device temperature overrun
Device temperature underrun
