TigoMaster 2TH – PROFINET User Manual

Page 62 of 69

Parameter

Value

Listen Only

I/O connection trigger type

Cyclic

Maximum number of I/O connections (class 1)

Maximum number of message connections (class 3)

Predefined standard objects

Identity Object (0x01) Message Router Object

(0x02) Assembly Object (0x04) Connection

Manager (0x06) Event Log Object (0x41)

DLR Object (0x47) QoS Object (0x48)

TCP/IP Interface Object (0xF5)

Ethernet Link Object (0xF6)

DHCP

Supported

BOOTP

Supported

Fixed IP address

Supported

Duplex mode

Half duplex, full duplex, auto-negotiation

MDI mode

MDI, MDI-X, Auto-MDIX

ACD (Address Conflict Detection)

Supported

Integrated switch

Supported

Reset services

CIP reset services: Identity Object, Reset

Services Type 0 and 1

Data transport layer

Ethernet II, IEEE 802.3

Interface type

10BASE-T, 100BASE-TX, isolated
