Artiglio Master Code User Manual 23
UK
G
A
B
C
D
E
F
10
G
A
B
F
11
A
C
12
B
D
13
A
- Remove the hoisting bracket (B,
Fig.12) unscrewing the screws and
washers (D, Fig. 12); assemble the
bead depressor retainer (C, Fig.
12) with the screws and washers (D,
Fig. 12).
- Assemble the wheel lifter (Fig. 13) with the screws
and washers (A, Fig. 13).
- Connect the machine to the mains and compressed air supply.
