Artiglio Master Code User Manual 89
UK
The inflation pressure must ALWAYS be checked using the pressure gauge and never
from the display.
PROCEDURE:
1. Verify that both upper and lower tyre beads and the rim
bead seat have been properly lubricated with an approved
mounting paste.
2. Lock the rim (Fig. 73).
3. Remove the valve stem core if not already done (Fig. 73a).
4. Press the key
to enable INFLATRON.
NOTE: If you are using a automatic working procedure the
device activation is automatically at the end of the procedure.
5. Press the arrow keys to select the required infla-
tion pressure.
The selected pressure value is displayed in red
6. Connect the inflation hose to the valve stem (Fig. 73b).
INFLATION PROCEDURE:
7. Press the key to start the cycle.
The wheel will be automatically inflated until it
reaches the selected pressure.
During the entire inflation stage, the pressure value
is not displayed and instead 3 horizontal red bars
appear (Fig. 73c).
At the end of inflation, the set pressure is displayed
again in green (Fig. 73d).
At this stage, inflation has ended.
8. Disconnect the Doyfe inflator chuck from the
wheel.
9. Mount the valve stem core (Fig. 73a).
73c
73d
73
73a
73b
WARNING
