94 Artiglio Master Code User Manual
To obtain a precise reading, the flat part of the sensor must be placed at right angles
as far as possible to the point to be measured.
NOTICE
- The thickness is shown on the display in mm and
in inches (see Fig. 75d).
- The background changes colour to immediately
indicate the status of conformity to the highway
code, in relation to the thickness measured.
White tyre in good conditions, thickness
> 4 mm
Orange tyre in fairly good conditions, thickness
between 3.9 mm to 2.0 mm
Yellow tyre in limit conditions, replacement
recommended, thickness between 1.6 mm to 1.9 mm
Red tyre to be replaced, thickness < 1.6 mm
- Press key
(see Fig. 75d) to exit the TREAD THICKNESS MEASURING SENSOR
and go back to the main screen.
TROUBLESHOOTING
The sensor does not work
Sensor connector disconnected
- Connect the connector (see Fig. 75e)
Sensor failure
- If the problem persists, contact technical as-
sistance.
The sensor does not reset to zero
Sensor failure
- If the problem persists, contact technical as-
sistance.
The sensor does not read correctly
Sensor not reset to zero
- Reset the sensor (see Resetting procedure)
Sensor failure
- If the problem persists, contact technical assistance.
75e
75d
