3-2 3-FEATURES
COROB™ TATOCOLOR
The machine may be accessorized with an optional device to center the hole of the pre-punched
can under the nozzle center with a laser (Bung hole locator or B.H.L.), this is useful for those
using pre-punched cylindrical or differently shaped cans.
The structure of the dispensing section has been designed to allow the computer, monitor and
keyboard to be housed on the machine. An auxiliary support plate for the computer may be
requested as an optional.
3.1.2 COROB™ TATOCOLOR TA
COROB™ TATOCOLOR model TA is equipped with manual shelf and automatic sliding cap. It also
features a manual punch with the possibility to add a manual plugger, to perforate and apply a
plastic plug on the can lids; the dispensing section is higher, and an adjustable arm (optional) can
be applied alongside the section with a support plate for the computer, to maintain the machine's
ergonomic qualities. The machine is made up of (Figure 3-2):
1. Central dispensing section
2. Right side canister section
3. Left side canister section
Figure 3-2 - COROB™ TATOCOLOR with ABS panels - model TA
3.2 Description of groups
This chapter gives a detailed description of the main machine groups.
3.2.1 Canister section
(Figure 3-3)
The side sections of the machine house canisters (1) suitable for containing the product to be
dispensed. To keep the colorant to be dispensed in the best possible condition of storage and
homogeneity, each canister is equipped with a stirrer with slanted blades (2), powered by a gear-
3
1
2
