8-6 8-ORDINARY MAINTENANCE
COROB™ TATOCOLOR
1. With the machine on, press and hold down the green enabling button to open the sliding
autocap.
2. Lower the punch side lever and keep it in this position.
3. Shut off the machine by pressing the ON-OFF button (chapter 6.2).
4. While the first person keeps the punch lever down, the second operator can disassemble the
punch tool as follows:
– Insert the threaded end of the device into the punch tool cavity.
– Turn the device clockwise all the way down; forcing it further, still clockwise, the punch
tool is released and then unscrewed. The punch tool remains firmly inserted on the device.
– Insert a screwdriver or similar into the hole on the punch tool to release the device.
– Turn the device counter-clockwise to separate it from the punch tool.
Always wear cut-proof gloves when handling the loose punch tool.
5. Follow the procedure described in point 4 in reverse order to reassemble the punch tool on
the machine.
6. Return the lever to its original position.
7. Switch the machine back on, by releasing the ON-OFF button. The sliding autocap closes
automatically.
Handle the punch tool with care to avoid damaging its cutting edge.
8.6 Filter maintenance
Number of operators: 1
Qualification: maintenance technician
The flow rate and precision of the machine could be jeopardized by excess residue in the
colorant, trapped in the pump filters (1) (Figure 8-3).
Filter clogging could reduce the machine flow rate, leading to imprecise dispensing (Figure
8-3).
