7-2 7-USING THE DISPENSER
COROB™ TATOCOLOR
COROB™ TATOCOLOR with sliding cap
According to the position of the humidifier cap, the management computer checks for the can
presence. Only after the can is placed on the shelf, thus causing the cap to open, it will be
possible to start dispensing.
1. Release the shelf by pulling the locking handle hidden beneath, raise or lower the shelf,
adjusting its height based on the size of the can to be used. Then release the handle to lock
the shelf in the desired position.
RISK OF CRUSHING.
The shelf position must be such that it allows the can -- to be lately placed -- to push the
cap opening bar.
2. Place the can on the shelf to push the cap opening bar inward and thus cause it to open;
make sure the can is properly positioned under the dispensing nozzles.
3. If the machine is fitted with the B.H.L., after having correctly positioned the can, the laser
beam will switch on automatically and the point it indicates on the can is the position that the
can hole must be in to perfectly match the nozzle center.
4. Confirm dispensing (next chapter).
COROB™ TATOCOLOR with sliding Autocap
The management computer checks for the can presence by means of a photocell located
underneath the nozzle center. Only when the can resting on the shelf is detected by the photocell
it will be possible to start dispensing.
1. Release the shelf by pulling the locking handle hidden beneath, raise or lower the shelf,
adjusting its height based on the size of the can to be used. Then release the handle to lock
the shelf in the desired position.
RISK OF CRUSHING.
The shelf position must be such that it does not cause the can to interfere with the
opening movement of the automatic sliding cap, but must anyway ensure proper
engagement of the photocell.
2. Place the can on the shelf; the sliding Autocap opens automatically when the can is detected
by the photocell. The sliding Autocap closes automatically when the shelf is lowered and the
photocell disengaged or when the can is removed from the shelf.
3. If the machine is fitted with the B.H.L., after having correctly positioned the can, the laser
beam will switch on automatically and the point it indicates on the can is the position that the
can hole must be in to perfectly match the nozzle center.
4. Confirm dispensing (next chapter).
7.2.2 Dispensing
After you have loaded the can and confirmed dispensing, keep hands away from the
dispensing area, until when the machine has finished dispensing.
Once the dispensing command has been received, the machine will begin to dispense the
colorants included in the formula in the set amounts. The dispensing time is the time required by
the colorant of which the greatest amount is used in the formula.
