3-FEATURES 3-9
COROB™ TATOCOLOR
The minimum and maximum dimensions of usable cans depend entirely on the type of accessories
with which the dispenser is equipped (humidifier cap, punch, plugger, etc.); the overall
dimensions of usable cans therefore depend on the machine configuration.
3.5.1 COROB™ TATOCOLOR TB
with sliding cap with sliding autocap
sheet
metal
ABS
sheet
metal
ABS
Min height 75 mm 60 mm 35 mm 20 mm
Max height 505 mm 490 mm 490 mm 475 mm
Max diameter (with hole in the center) 230 mm
Max diameter (with hole not in the center) 340 mm
3.5.2 COROB™ TATOCOLOR TA
with sliding autocap
sheet metal ABS
Min height 75 mm 60 mm
Max height 575 mm 560 mm
Max diameter (with hole in the center) 310 mm
Max diameter (with hole not in the center) 340 mm
3.6 Minimum computer requirements
The minimum computer requirements needed to manage the machine depend entirely on the
application software used.
See the program manual for a list of the minimum computer requirements.
In any case, the computer must have at least two serial ports (RS232 or USB), needed to
communicate with the dispenser and connect the calibration scale (the type of serial port depends
on the scale type).
3.7 Intended and improper use
The automatic dispenser is a device to automatically and simultaneously dispense (or distribute)
fluid colorant products into containers (metal or plastic canisters, cans or bins) of the size
indicated in chapter 3.5, pre-filled with base, to produce finished products such as paints, dyes,
enamels, and inks of the desired hue.
The machine must be used only within the limitations set forth by the technical
specifications and according to the procedures described in this manual.
Any use other than that stated, which cannot be implied or deduced from this manual, is
to be considered prohibited.
