5-INSTALLATION 5-1
COROB™ TATOCOLOR
5 INSTALLATION (by qualified personnel)
5.1 General warnings
Only qualified or appropriately trained personnel are authorized to install the machine.
Before installing the machine, read the instructions in this chapter carefully to ensure the
safety of the personnel involved and avoid damaging the machine.
Once the machine has been unpacked and placed in its operating site, it must be installed.
5.2 Conditions for proper installation
You must observe the environment conditions described in chapter 4.3.
You must also prepare an electrical power line in accordance with the voltage and frequency
required by the machine, listed on the identification plate (chapter 2.4).
The line must be protected from overloads, short-circuits and direct contacts according to current
regulations.
Check the grounding of the power supply system as required by local regulations before
installing or powering the machine.
Installing a COROB™ dispenser involves:
installing any accessories
filling the canisters and purging the circuits to eliminate lubricant from the pumps
connecting the computer to the machine and installing the application software
configuring the machine via the management program
moistening the sponge in the humidifier cap
5.3 Installing accessories
Standard and optional accessories are normally pre-installed on the machine. Only in certain
situations do they need to be installed.
5.3.1 Mounting the support plate for the computer
Proceed with the installation as follows:
1. Unpack the support plate for the computer, by removing the bubble plastic wrapping.
2. Using a 13 mm hexagonal wrench, remove the screw and washer (1) of the pin (2) located on
the arm fixed to the machine, so as to insert the computer support plate (Figure 5-1).
3. Insert the support plate in the pin.
4. To fix the support plate to the arm, fit back the screw and washer previously removed (Figure
5-2). If you tighten the screw too much, adjusting the plate position will result more difficult.
