124 • 4-Series™ Control Systems Product Manual — Doc. 8559B
l
If Slave Mode is turned on, enter the IP address or host name of the primary control
system in the Master IP/Hostname text field.
l
If Slave Mode is turned on, enter the IPIDfor the connection to the primary control system
in the IPIDtext field.
Program Slot Management
NOTE:For more information on managing programs on a 4-Series control system, refer to
Program Management (on page189).
Select the + (plus)icon next to Program Slot Management to display the following program
management settings.
Each program slot is represented in a table that provides the following information and controls:
l
Slot:The program slot number (1-10)
NOTE:The MC4, MC4-I, and RMC4 are designed to run a single program out of the
box. The optional modular programming architecture (MPA) add-on allows the RMC4
to run up to ten programs simultaneously via a SW-RMC3-10PROGlicense.
l
Program Name:The name for the control system program
l
Registration:The registration status of the program
l
Execution:The execution status of the program
l
Program Editing: Provides the following program editing controls:
o
Select the Upload Program button to load a new program to the control system.
Instructions for loading a new program to the control system are provided below.
o
Select the Edit Program button to edit information about the program (if
available).
o
If the program is unregistered, select the Register Program button to register
the program with the control system.
o
If the program is registered, select the Unregister Program button to unregister
the program from the control system.
l
Program Execution:Provides the following program execution controls:
o
If the program is stopped, select the Start Program button to start the program.
o
If the program is running, select the Stop Program button to stop the program.
o
Select the Restart Program button to restart the program.
