Curtis 1226 User Manual

2 — INSTALLATION AND WIRING
Curtis Model 1226 – September 2019
Return to TOC
pg. 8
Table 5 J3 Connector
Pin Number Typical Function Switch Input Analog Input LED Driver
J3-1 Keyswitch input
J3-2 Horn driver
J3-3 Interlock input 7
J3-4 Emergency reverse NC input 3 3 3
J3-5 BDI output
J3-6 Speed limit pot input 2 2
J3-7 Throttle pot wiper 1 1
J3-8 Reverse input 8 2
J3-9 Push input 9
J3-10 Coil return
J3-11 Generic driver 3
J3-12 Generic driver 2
J3-13 I/O ground
J3-14 Emergency reverse NO input 10
J3-15 Charge inhibit 11
J3-16 Throttle pot high 4 4
J3-17 Forward input 12
J3-18 Mode input 13 1
