Curtis 1226 User Manual

3 — PROGRAMMABLE PARAMETERS
Curtis Model 1226 – September 2019
Return to TOC
pg. 30
Fine Tuning Menu
Use the Fine Tuning menu’s parameters to dene the high and low speed thresholds for all parameters
with names ending in HS and LS. For examples, see the following topics:
Understanding Low and High Speed Acceleration
Understanding Low and High Speed Brake Deceleration (page 32)
SPEED MODE MENU — FINE TUNING MENU
PARAMETER VALUES DEFAULT DESCRIPTION
HS(High Speed) 0%-100% 90% Sets the percentage of the Speed Scaler parameter voltage above
which the high speed (HS) parameters are used.
LS(Low Speed) 0%-100% 10% Sets the percentage of the Speed Scaler parameter voltage below
which the low speed (LS) parameters are used.
