Cyclades alterpath pm8 - Table A-3: Pm8 I-10 A Specifications; Table A-4: PM10-15 A Specifications

Electrical and Hardware Specifications
86 AlterPath PM Installation, Administration, and User’s Guide
The following table lists the specifications for the AlterPath PM8i-10.
The following table lists the specifications for the AlterPath PM10-15A.
Table A-3: PM8i-10A Specifications
Characteristics Specifications
Input Voltage
100-240 VAC
Max Output Current Total
10A
Max Output Current Each Outlet
10A
Operating Temperature
50-122 ºF (10-50 ºC)
Relative Humidity
5%-95%
Weight
5 lb (2.3 kg)
Physical Dimensions (W x D x H)
17 x 3.7 x 2.63 in
(43.2 x 9.4 x 6.7 cm)
Table A-4: PM10-15A Specifications
Characteristics Specifications
Input Voltage
100-125 VAC
Max Output Current Total
15A (de-rated to 12A)
Max Output Current Each Outlet
15A (de-rated to 12A)
Operating Temperature
50-122 ºF (10-50 ºC)
Relative Humidity
5%-95%
Weight
7.8 lb (3.5 kg)
Physical Dimensions (W x D x H)
1.75 x 8 x 9 in
(4.4 x 20.3 x 22.9 cm)
