Electrical and Hardware Specifications
94 AlterPath PM Installation, Administration, and User’s Guide
The following table lists the specifications for the AlterPath PM20i-20A and
PM20i-L20A.
The following table lists the specifications for the AlterPath PM20i-L30A
model.
Table A-16: PM20i-20A and PM20i-L20A Electrical Specifications
Characteristics Specifications
Input Voltage
100-240 VAC
Max Output Current Total
20A (de-rated to 16A)
Max Output Current Each Outlet
10A (de-rated to 8A)
Operating Temperature
32-122 ºF (0-50 ºC)
Relative Humidity
5%-95%
Weight
13.5 lb (6.1 kg)
Physical Dimensions (W x D x H)
2.2 x 2.8 x 66 in
(5.6 x 7.1 x 167.6 cm)
Table A-17: PM20i-L30A Specifications
Characteristics Specifications
Input Voltage
100-240 VAC
Max Output Current Total
30A (de-rated to 24A)
Max Output Current Each Outlet
10A (de-rated to 8A)
Operating Temperature
32-122 ºF (0-50 ºC)
Relative Humidity
5%-95%
