Cyclades alterpath pm8 - Table A-10: Pm10 I-20 A Specifications; Table A-11: Pm10 I-32 A and Pm10 I-32 Au Specifications

Electrical and Hardware Specifications
90 AlterPath PM Installation, Administration, and User’s Guide
The following table list the electrical specifications for the AlterPath PM10i-
20A.
The following table lists the specifications for the AlterPath PM10i-32A and
PM10i-32Au model.
Table A-10: PM10i-20A Specifications
Characteristics Specifications
Input Voltage
100-240 VAC
Max Output Current Total
20A (de-rated to 16A)
Max Output Current Each Outlet
10A (de-rated to 8A)
Operating Temperature
50-122 ºF (10-50 ºC)
Relative Humidity
5%-95%
Weight
8.4 lb (3.8 kg)
Physical Dimensions (W x D x H)
19 x 8 x 1.75 in
(48.3 x 20.3 x 4.4 cm)
Table A-11: PM10i-32A and PM10i-32Au Specifications
Characteristics Specifications
Input Voltage
100-240 VAC
Max Output Current Total
32A
Max Output Current Each Outlet
10A
Operating Temperature
32-122 ºF (0-50 ºC)
Relative Humidity
5%-95%
