Introduction 11
Models and Components
AlterPath PM8i
The AlterPath PM8i has the following features:
• One 240VAC/8A power plug (IEC320-C14)
See “AlterPath PM8i-15A and AlterPath PM10i-10A Power Cables” on
page 23 for a list of which power cables are supplied by region.
• Eight 240VAC/8A power receptacles (IEC320-C14)
• 240VAC/10A supplementary protector
• Vertical (zero U) & Horizontal (1.5 U) mounting
The following graphic depicts the AlterPath PM8i.
Figure 1-5: AlterPath PM8i
Power Inlet
Power Outlets (IEC320-C14)
OUT Port
In Port Digital Current Display
