Cyclades alterpath pm8 - Figure 1-3: the Alterpath PM with a Cyclades Management Device

140 pages

Save Page as PDF

To Next Page

To Previous Page

Introduction 7

Hardware Configuration Options

Figure 1-3: The AlterPath PM with a Cyclades Management Device

Additional AlterPath PMs with

up to a total of 128 outlets

can be daisy-chained

Server Switch

PM #2

PM #1

PM #3

PM #4

Power Source

AlterPath OnSite
