AlterPath PM10i
The AlterPath PM10i has the following features:
• One of the following power plugs:
• 240VAC/10A power plug (IEC320-C14)
• 240VAC/16A power plug (IEC320-C20)
• Ten 240VAC/10A power receptacles (IEC320-C13)
• 240VAC/10A/20A supplementary protector
• Horizontal (1U) mounting
The following graphic depicts the back of the AlterPath PM10i.
Figure 1-7: AlterPath PM10i Back
The following graphic depicts the back of the AlterPath PM10i.
Figure 1-8: AlterPath PM10i Front
IN port
OUT port
10 IEC320-C13 Power Outlets
IEC320-C14 Power Inlet
Digital Current DisplayPower Outlet LEDs
