Specifications 87
Electrical and Hardware Specifications
The following table lists the specifications for the AlterPath PM10-20A and
PM10-L20A.
The following table lists the specifications for the AlterPath PM10-L30A.
Table A-5: PM10-20A and PM10-L20A Specifications
Characteristics Specifications
Input Voltage
100-125 VAC
Max Output Current Total
20A (de-rated to 16A)
Max Output Current Each Outlet
15A (de-rated to 12A)
Operating Temperature
50-122 ºF (10-50 ºC)
Relative Humidity
5%-95%
Weight
8.4 lb (3.8 kg)
Physical Dimensions (W x D x H)
1.75 x 8 x 9 in
(4.4 x 20.3 x 22.9 cm)
Table A-6: PM10-L30A Specifications
Characteristics Specifications
Input Voltage
100-125 VAC
Max Output Current Total
30A (de-rated to 24A)
Max Output Current Each Outlet
15A (de-rated to 12A)
Operating Temperature
50-122 ºF (10-50 ºC)
Relative Humidity
5%-95%
