Interface Pinouts
96 AlterPath PM Installation, Administration, and User’s Guide
Interface Pinouts
The following table illustrates the AlterPath PM's pinouts for the In and OUT
RS-232 serial ports (RJ-45F connectors).
Table A-19: Pinouts for In and OUT RS-232 serial ports
Signal Name/Function I/O In Pin OUT Pin
RTS
Request to Send (O) 5 1
DTR
Data Terminal Ready (O) 7 2
TxD
Transmit Data (O) 6 3
Gnd
Ground N/A 4 4
CTS
Clear to Send (I) 1 5
RxD
Receive Data (I) 3 6
DCD
Data Carrier Detect (I) 2 7
DSR
Data Set Ready (I) 8 8
