Installation 21
Reviewing the Shipping Box Contents
CAB0018 RJ-45 to RJ-45 7ft.
CAT5 cable
Used for the following:
• Along with an adapter, to
connect a terminal or PC to
the IN port. See “To Access
the Console” on page 34.
• To connect to a Cyclades
console or KVM
management device.
• To connect to another
AlterPath PM in a daisy
chain. See “To Daisy Chain
a PM” on page 31.
ADB0036 RJ-45 to DB-9F
straight-through
adapter
Along with an RJ-45 cable,
used to connect a terminal or
PC to a PC’s COM port. See
“To Access the Console” on
page 34.
CON0132 RJ-45 loopback
connector
In the case that the
administrator forgets the
admin's password, this is
used to place in the OUT port
to gain temporary access to
the box using the factory
default password.
See “To Reset the Admin
Password Using the
Loopback Connector” on
page 41.
Table 2-1: PM Shipping Box Contents, Part Numbers, and Description (Continued)
5
Item P/N Description Purpose
