Commands
68
AlterPath PM Inst
allation, Administration
, and User
’s Guid
e
Arguments
<outlet number>
O
utlet number
, such as “5”
<name>
Desired outlet name
Examples
T
o name outlet 4 as
nowher
e
, type:
pm>
name 4 nowhere
4: Outlet now named nowhere
87
89
