DAELIM S-FIVE Service Manual

10-21
FRONT WHEEL/FRONT FORK/STEERING
● Remove the upper ball race/ steering bottom cone race.
TOOL : BALL RACE DRIVER
NOTE
·Check all of the races and balls for damage or
abnormal wear and replace as necessary.
·If the vehicle has been involved in a collision, the
steering stem may be damaged.
STEERING STEM INSTALLATION
● Insert the upper/under ball race into the steering head
pipe.
● Using a steering stem driver, drive the steering stem
bottom cone race into the steering stem.
● Insert the ball race after applying grease thereto.

DAELIM S-FIVE Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Tires (Front)	120/70-12
Tires (Rear)	130/70-12
Engine Type	4-Stroke, Air-Cooled
Transmission	Automatic
Fuel Capacity	5.5 liters
